R134a Heat Pump Marine Heat Exchanger MHTA-1 Corrosion Prevention Low Water Resistance

R134a Marine Heat Exchanger

Heat Pump Marine Heat Exchanger

Marine Heat Exchanger MHTA-1

Place of Origin:

Guangdong, China

Brand Name:

Gimleo

Certification:

RoHS

Request A Quote

R134a Heat Pump Marine Heat Exchanger MHTA-1 Corrosion Prevention Low Water Resistance

Product Details

Applicable Industries:

Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C

Showroom Location:

None

Video Outgoing-inspection:

Not Available

Machinery Test Report:

Not Available

Warranty Of Core Components:

1 Year

Core Components:

Condition:

New

Structure:

Tube Heat Exchanger, Type A

Liquid Flow Rate:

1.5 M^3/h

Maximum Working Pressure:

R:52 Bar, W:12 Bar

Weight:

3.5 KG

Warranty:

1 Year

Working Temperature Range:

0~50℃

Key Selling Points:

High Safety Level

Product Name:

PVC Titanium Heat Exchanger (Heat Or Cool Mode)

Heat Capacity:

3.5kw (12,000BTU/h)

Water Flow:

1.5m³/h

Tube Material:

Pure Titanium Seamless Tube

Shell Material:

PVC

Used As:

Condenser Or Evaporator

Port:

Rongqi Port Or Leliu Port

Highlight:

R134a Marine Heat Exchanger

Heat Pump Marine Heat Exchanger

Marine Heat Exchanger MHTA-1

Payment & Shipping Terms

Price

$92.00/sets 1-49 sets

Packaging Details

Plywood case

Supply Ability

1500 Piece/Pieces per Week

Refrigerant Connector Sea Water Heat Exchanger With And Titanium Tube For Industrial Cooling Systems

Get Best Price

ETA-0.5 Titanium Heat Exchanger Maximum Working Pressure R 50 bar for Heat Management

Get Best Price

Advanced Sea Water Heat Exchanger Designed For Optimal Heat Transfer In Harsh Seawater Conditions

Get Best Price

Robust Sea Water Heat Exchanger For Corrosion Resistance In Harsh Marine Environments

Get Best Price

+8618929900710

sales06@gimleo.com

86-757-2837-8561

Contact Now

Product Description

R134a Heat Pump Marine Heat Exchanger MHTA-1 Corrosion Prevention And Low Water Resistance

Products Description

Product name	PVC Titanium Heat Exchanger (Heat or Cool mode)
Type	MHTA series
Model number	MHTA-1
Heating capacity	3.5kw
Water flow	1.5m³/h
Use as	Condenser,Evaporator

Series Products

Product Introduction :

Titanium has the super strong corrosion resistant ability. Our titanium heat exchanger use seamless pure titanium tube as heat conductor, exhibits outstanding resistance to corrosion in a wide range of aggressive media.

Due to its good properties ,the titanium heat exchanger widely used in: Swimming pool equipment, Aquarium chiller, Marine refrigerant system, Solar energy heater, Aquaculture, Pharmacy, Food industry, Electroplating industry and some heat recovery from the waste water or exhaust gas.

Product Features :

• Self-patented technology.
• Seamless pure titanium tube has super strong corrosion proof ability and high intensity.
• Due to its perfect structure design, the PVC shell can stand high working pressure. The max working pressure in water side can be 2.5 MPa. Titanium tube can stand 5.2MPa high pressure.

• Its loading capacity can pass the CE, UL, ETL requirement, 100,000 times alternating pressure test shows it can be used more than 20 years

Product material :

[ The heat transfer tube ]: Seamless pure titanium tube . Thickness 0.6 mm. The Grade is TA1

[ Shell ]:high quality PVC material . All the parts RoHS conformance.

Details Images

Product Application

Product Categories

Company Profile

Company Introduction

Gimleo Heat Exchanger Co., Ltd. is located in Shunde , Foshan city , a professional manufacturer of energy- saving heat exchanger equipment integrated with R& D, manufacture, sales and service.

Gimleo, founded in 2005, is based on high tech and high quality with advanced manufacturing facilities, testing equipment along with many high-educated professional staff; especially we’ve established a heat exchange capacity-testing lab ahead of others in the industry.

Our products cover high efficiency tube in shell heat exchanger, titanium heat exchanger, nickel-copper tube in shell heat exchanger, coaxial heat exchanger, etc. which can be widely used in swimming pool equipment, aquarium chiller, marine refrigerant units, air source heat pump, water source heat pump, aquaculture, pharmacy, food industry, electroplating industry and heat recovery from the waste water or exhaust gas.

We deeply realize the importance of scientific management and technical innovations.Firstly Gimleo has passed the ISO 9001 improving and strengthening the entire quality control process from R& D to sales.Meanwhile, the company establishes the perfect information platform for the whole manufacturing and R& D system-ERP. In 2016 .We had passed 174 environmental REACH testing and certification.

After several years of development, Gimleo has become a leading domestic enterprise in manufacturing heat exchangers, in great cooperating relationships with about 150 companies.
