ETA-3 Chiller Titanium Evaporator Energy Saving With 12.7mm Refrigerant Inlet

Chiller Titanium Evaporator

ETA-3 Titanium Evaporator

Titanium Evaporator Energy Saving

Place of Origin:

Guangdong, China

Brand Name:

Gimleo

Request A Quote

ETA-3 Chiller Titanium Evaporator Energy Saving With 12.7mm Refrigerant Inlet

Product Details

Applicable Industries:

Hotels, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Food Shop, Construction Works , Energy & Mining, Food & Beverage Shops

Showroom Location:

None

Video Outgoing-inspection:

Not Available

Machinery Test Report:

Not Available

Warranty Of Core Components:

Not Available

Core Components:

Condition:

New

Structure:

Smooth Titanium Tube, Coil Heat Exchanger

Liquid Flow Rate:

2.0 M3 Per Hour

Maximum Working Pressure:

Refrigerant Side 5.2MPa; Water Side 2.5MPa

Voltage:

OEM

Weight:

8.6 KG

Dimension(L*W*H):

Multiple Choices

Warranty:

1 Year

Working Temperature Range:

0~45℃

Key Selling Points:

Energy Saving

Product Name:

Heat Exchanger Chiller Evaporator

Application:

Swimming Pool Boiler

Titanium Grade:

TA1

Water Flow (M3/h):

2.0

Inner Dia. Of Water Connector:

50mm

Refrigerant Inlet:

12.7mm

Refrigerant Outlet:

15.88mm

Dimension(LxWxH):

340x240x690 Mm

Net Weight:

8.6 Kg

Highlight:

Chiller Titanium Evaporator

ETA-3 Titanium Evaporator

Titanium Evaporator Energy Saving

Payment & Shipping Terms

Price

$448.00/units 1-49 units

Packaging Details

pallet, crate,plywood cases

Supply Ability

2000 Unit/Units per Month

Energy-Saving Chiller Gimleo Heat Exchanger With High Refrigeration ETA3 Efficiency And Corrosion Resistance

Get Best Price

Video

Corrosion-Resistant Chiller Heat Exchanger With Screwed Titanium Tube And PVC Shell For Aquarium MHTA-1

Get Best Price

Video

Gimleo Versatile Chiller Heat Exchanger With Titanium Evaporator ETA3 For Customized Industrial Cooling

Get Best Price

800HP Stainless Steel Chiller Heat Exchanger High Performance Cooling Application

Get Best Price

+8618929900710

sales06@gimleo.com

86-757-2837-8561

Contact Now

Product Description

ETA-3 Chiller Titanium Evaporator With 12.7mm Refrigerant Inlet And Multiple Choices

Products Description

Product name	PVC Titanium Heat Exchanger (Cool mode)
Type	ETA series
Model number	ETA-3
Cooling capacity	7.5kw
Water flow	2.0m³/h
Use as	Evaporator

Series Products

Product Introduction :

Titanium has the super strong corrosion resistant ability. Our titanium heat exchanger use seamless pure titanium tube as heat conductor, exhibits outstanding resistance to corrosion in a wide range of aggressive media.

ETA series heat exchanger is mainly used as evaporator.It has great refrigeration efficiency,commonly used in seafood,fish ponds and cooling,food refrigeration,chemical media,cooling and other equipment.

Product Features :

• Self-patented technology.

• It has great refrigeration efficiency.
• Seamless pure titanium tube has super strong corrosion proof ability and high intensity.
• Due to its perfect structure design, the PVC shell can stand high working pressure. The max working pressure in water side can be 2.5 MPa. Titanium tube can stand 5.2MPa high pressure.

• Its loading capacity can pass the CE, UL, ETL requirement, 100,000 times alternating pressure test shows it can be used more than 20 years

Product material :

[ The heat transfer tube ]: Seamless pure titanium tube . Thickness 0.6 mm. The Grade is TA1

[ Shell ]:high quality PVC material . All the parts RoHS conformance.
