ETA-0.5 Titanium Heat Exchanger Maximum Working Pressure R 50 bar for Heat Management

R 50 bar Titanium Heat Exchanger

Heat Management Titanium Heat Exchanger

Place of Origin:

Guangdong, China

Brand Name:

Gimleo

Certification:

RoHS

Request A Quote

ETA-0.5 Titanium Heat Exchanger Maximum Working Pressure R 50 bar for Heat Management

Product Details

Condition:

New

Structure:

Tube Heat Exchanger, Type A

Liquid Flow Rate:

0.4m^3/h

Maximum Working Pressure:

R:50 Bar, W:5 Bar

Voltage:

Dimension(L*W*H):

370mm(height)

Warranty:

1 Year

After-sales Service Provided:

No After-sales Service, Online Support, No Overseas Service Provided

Application:

Evaporator

Shell:

PVC

Tube:

Pure Titanium Seamless Tube

Surface:

Covered Sponge For Insulation

Product No.:

11024

Port:

Rongqi Port Or Leliu Port

Highlight:

R 50 bar Titanium Heat Exchanger

Heat Management Titanium Heat Exchanger

Payment & Shipping Terms

Minimum Order Quantity

50 sets

Price

$60.00/sets >=50 sets

Packaging Details

Plywood box

Supply Ability

1800 Set/Sets per Week

Refrigerant Connector Sea Water Heat Exchanger With And Titanium Tube For Industrial Cooling Systems

Get Best Price

ETA-0.5 Titanium Heat Exchanger Maximum Working Pressure R 50 bar for Heat Management

Get Best Price

Advanced Sea Water Heat Exchanger Designed For Optimal Heat Transfer In Harsh Seawater Conditions

Get Best Price

Robust Sea Water Heat Exchanger For Corrosion Resistance In Harsh Marine Environments

Get Best Price

+8618929900710

sales06@gimleo.com

86-757-2837-8561

Contact Now

Product Description

Work Condition:
1)Refrigerant side(In the tube): R22,R134a,R407c,R410a
2)Water side (Between the tube and PVC shell):Nature water,seawater,other corrosive solution.

Material:
1)Heat transfer Tube: Thickness 0.6mm Seamless pure titanium tube.

2)shell: PVC.

Features:
1)Molded cups,more safe,small and beautiful.

2)Seamless pure titanium tube has super strong corrosion proof ability and high intensity.

3) The seamless titanium tube was tested by 5.0MPa pressure precise Halogen Leak Detection to make sure the tube is strong and not leakage .

4)The PVC shell was tested by 0.5Mpa water pressure to make sure the water system not leakage .
5)It suitable for seawater,fish pool,aquarium chillers,or cooling some corrosive solution.

Specification:

Model				Ti Tube	diameter	Height	connection(mm)
Model	KW	BTU/h	R Ton	mm	mm	mm	refrigeration	water
ETA-0.33	1.0	3412.0	0.28	12.70.552500	110	330	9.52,9.52	1"
ETA-0.5	1.3	4435.6	0.37	*12.70.554000*	110	330	9.52,9.52	1"
ETA-0.75	1.9	6482.8	0.54	12.70.556000	160	450	9.52,12.7	1.5"
ETA-1	2.5	8530.0	0.71	12.70.557500	160	480	9.52,12.7	1.5"
ETA-1.5	3.75	12795.0	1.07	12.70.5511500	160	590	9.52,12.7	1.5"
ETA-2	5	17060.0	1.42	12.70.5515000	160	630	9.52,12.7	1.5"
ETA-3	7.5	25590.0	2.13	190.515000	250	480	12.7,15.88	1.5"
ETA-4	10	34120.0	2.84	190.520000	250	550	12.7,15.88	1.5"
ETA-5	12.5	42650.0	3.55	190.525000	250	580	12.7,19	1.5"
ETA-7.5	18.5	63122.0	5.26	250.528500	315	600	12.7,19	2"
ETA-10	25	85300.0	7.11	2-190.525000	355	640	15.88,25	2"
ETA-15	37.5	127950.0	10.66	2-250.528500	355	790	15.88,25	2"

Notice:The data list is our suggested data,We can produce any catacity heat exchagers according customer requirement and design.
